Parametry techniczne SC77

ENGINE



Type

Liquid-cooled 4-stroke 16-valve DOHC Inline-4

Engine Displacement (cm3)

999cc

No. of Valves per Cylinder

4

Bore ´ Stroke (mm)

76 x 55

Compression Ratio

13:01

Max. Power Output

141kW/13,000rpm

Max. Torque

116Nm/11,000rpm

Oil Capacity

3.4L

FUEL SYSTEM



Carburation

PGM-DSFI

Fuel Tank Capacity

16L

Fuel Consumption

TBC

ELECTRICAL SYSTEM



Starter

Electric

Battery Capacity

12V-4.5AH(Li-ion)

ACG Output

0.42kw

DRIVETRAIN



Clutch Type

Wet, multiplate clutch

Transmission Type

6-speed

Final Drive

Chain

FRAME



Type

Diamond; aluminium composite twin spar

CHASSIS



Dimensions (LxWxH)

2,065mm x 715mm x 1125mm

Wheelbase

1404mm

Caster Angle

23.3°

Trail

96mm

Seat Height

820mm

Ground Clearance

129mm

Kerb Weight

195kg

Turning radius

-

SUSPENSION



Type Front

Telescopic inverted fork with an inner tube diameter of 43mm, and a NIX30 Smart-EC (OHLINS) Front Fork with preload, compression and rebound adjustments, 120mm stroke

Type Rear

Unit Pro-Link with gas-charged TTX36 Smart-EC (Öhlins) damper featuring preload and compression and rebound damping adjustment, 60mm stroke

WHEELS



Rim Size Front

17 inch

Rim Size Rear

17 inch

Tyres Front

120/70ZR17 58W

Tyres Rear

190/50ZR17 73W

BRAKES

ABS System Type

2 Channel

INSTRUMENTS & ELECTRICS



Instruments

TFT-LCD

Security System

HISS

Headlight

LED

Taillight

LED
